Residential and Small Commercial Onsite Wastewater Treatment Aeration Pumps

News

2024 Onsite Wastewater Mega-Conference – October 20-23, 2024

More News »

Why do most Aerobic Treatment Unit (ATU) manufacturers supply HIBLOW linear air pumps with their onsite wastewater treatment systems?

Four main reasons: our quality, reliability, performance, and availability.

In many onsite installations, the air pump is the septic system’s only moving part. So it must be dependable. HIBLOW pumps work 24 hours a day, every day of the year. They set the industry standard for reliability and service life.

Built In-House

We design, engineer, and manufacture all HIBLOW pumps in our own facilities. We don’t buy pumps from other companies and re-brand them. And we don’t use contract manufacturers.

Fully Tested

Every HIBLOW linear air pump is fully tested and certified for quality in your application before it is packaged and shipped to you from one of our factories.

Fully Covered

If you read closely, the warranties for most competitive pumps don’t cover the diaphragms. We do. After all, what good is a warranty if it doesn’t include the working parts?

Whisper Quiet

HIBLOW residential models are below 36 dBA. Larger commercial units are under 48 dBA. Whether installed right next to the patio, or even indoors, your customer won’t complain about noise.

To purchase a HIBLOW pump, please contact us for your closest, or most convenient distributor. If you are unsure which HIBLOW pump model you need, please contact your treatment system manufacturer.

Residential and Small Commercial Wastewater Aeration Pumps

DUO Series Select a model for full specifications

Product Details – DUO 60

  • Max Flow (lpm)100
  • Max Cont Operating Pressure (kPa)20
  • Power Consumption (Watts)39
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)6

Features

  • Dual outlet ports with integrated cam-style valves and programmable timer controller to alternate between two aeration processes
  • Available with integral low-pressure alarms.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Equipped with thermal overload protection
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – DUO 80

  • Max Flow (lpm)110
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)58
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)6

Features

  • Dual outlet ports with integrated cam-style valves and programmable timer controller to alternate between two aeration processes
  • Available with integral low-pressure alarms.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Equipped with thermal overload protection
  • Includes pressure tap location for external alarm sensor

Download Specifications

HP Alarm Units Select a model for full specifications

Product Details – HP-40A

  • Max Flow (lpm)60
  • Max Cont Operating Pressure (kPa)20
  • Power Consumption (Watts)38
  • Noise Level (dBA @ 1m.)32
  • Weight (kg)6.1

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 12 to 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-60A

  • Max Flow (lpm)100
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)51
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)7.4

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 24 to 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-80A

  • Max Flow (lpm)120
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)71
  • Noise Level (dBA @ 1m.)39
  • Weight (kg)7.4

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 24 to 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-100A

  • Max Flow (lpm)110
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)100
  • Noise Level (dBA @ 1m.)38
  • Weight (kg)8.9

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-100LLA

  • Max Flow (lpm)130
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)75
  • Noise Level (dBA @ 1m.)42
  • Weight (kg)9.4

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-120LLA

  • Max Flow (lpm)150
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)100
  • Noise Level (dBA @ 1m.)42
  • Weight (kg)9.4

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-120A

  • Max Flow (lpm)150
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)125
  • Noise Level (dBA @ 1m.)40
  • Weight (kg)8.9

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-150A

  • Max Flow (lpm)200
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)155
  • Noise Level (dBA @ 1m.)47
  • Weight (kg)9

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-200A

  • Max Flow (lpm)200
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)250
  • Noise Level (dBA @ 1m.)48
  • Weight (kg)9

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

HP-Series Select a model for full specifications

Product Details – HP-20

  • Max Flow (lpm)32
  • Max Cont Operating Pressure (kPa)15
  • Power Consumption (Watts)17
  • Noise Level (dBA @ 1m.)32
  • Weight (kg)3.2

Features

  • Standard model available only for 120VAC applications.
  • Pumps equipped with thermal overload protection.

Download Specifications

Product Details – HP-40

  • Max Flow (lpm)80
  • Max Cont Operating Pressure (kPa)20
  • Power Consumption (Watts)38
  • Noise Level (dBA @ 1m.)32
  • Weight (kg)5.7

Features

  • Available with integral low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 12 to 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – HP-60

  • Max Flow (lpm)100
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)51
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)7

Features

  • Available with integral low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 24 to 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – HP-80

  • Max Flow (lpm)120
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)71
  • Noise Level (dBA @ 1m.)36
  • Weight (kg)7

Features

  • Available with low pressure alarms for 120VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Dual port models available with internal flow switching solenoids and programmable timers for aerator/skimmer applications.
  • Contact us for custom voltage applications, including 24 – 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-100

  • Max Flow (lpm)110
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)100
  • Noise Level (dBA @ 1m.)38
  • Weight (kg)8.5

Features

  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-100LL

  • Max Flow (lpm)130
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)75
  • Noise Level (dBA @ 1m.)42
  • Weight (kg)9

Features

  • Available with low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – HP-120

  • Max Flow (lpm)150
  • Max Cont Operating Pressure (kPa)25
  • Power Consumption (Watts)125
  • Noise Level (dBA @ 1m.)40
  • Weight (kg)8.5

Features

  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – HP-120LL

  • Max Flow (lpm)150
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)100
  • Noise Level (dBA @ 1m.)45
  • Weight (kg)9

Features

  • Available with low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – HP-150

  • Max Flow (lpm)200
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)155
  • Noise Level (dBA @ 1m.)47
  • Weight (kg)9

Features

  • Available with integral low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – HP-200

  • Max Flow (lpm)240
  • Max Cont Operating Pressure (kPa)30
  • Power Consumption (Watts)250
  • Noise Level (dBA @ 1m.)48
  • Weight (kg)9

Features

  • Available with integral low-pressure alarms for 120VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

XP Alarm Series Select a model for full specifications

Product Details – XP-40A

  • Max Flow (lpm)70
  • Max Cont Operating Pressure (kPa)20
  • Power Consumption (Watts)24
  • Noise Level (dBA @ 1m.)30
  • Weight (kg)4.1

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 12 to 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – XP-60A

  • Max Flow (lpm)90
  • Max Cont Operating Pressure (kPa)23
  • Power Consumption (Watts)40
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)4.3

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 12 to 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

Product Details – XP-80A

  • Max Flow (lpm)100
  • Max Cont Operating Pressure (kPa)27
  • Power Consumption (Watts)64
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)4.3

Features

  • Integral low-pressure alarm
  • Standard UL approved 120 VAC models
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 12 to 48 VDC system applications using external PWM controllers for modulating pump flow.

Download Specifications

XP Series Select a model for full specifications

Product Details – XP-40

  • Max Flow (lpm)70
  • Max Cont Operating Pressure (kPa)20
  • Power Consumption (Watts)24
  • Noise Level (dBA @ 1m.)30
  • Weight (kg)4.1

Features

  • Available with integral low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 24 to 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – XP-60

  • Max Flow (lpm)90
  • Max Cont Operating Pressure (kPa)23
  • Power Consumption (Watts)40
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)4.3

Features

  • Available with integral low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 24 to 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Product Details – XP-80

  • Max Flow (lpm)100
  • Max Cont Operating Pressure (kPa)27
  • Power Consumption (Watts)64
  • Noise Level (dBA @ 1m.)35
  • Weight (kg)4.3

Features

  • Available with integral low-pressure alarms for 120 VAC applications.
  • Standard UL approved 120 VAC models, and 230 VAC CE compliant models available.
  • Pumps equipped with thermal overload protection.
  • Contact us for custom voltage applications, including 24 to 48 VDC system applications using external PWM controllers for modulating pump flow.
  • Includes pressure tap location for external alarm sensor

Download Specifications

Also Available: Manifolds for HP Series

Manifolds for connecting multiple HIBLOW HP Series pumps in parallel for higher flows. Enables connection of up to 5 pumps in parallel with a single exhaust port.
Learn More »

(734) 944-5032 Call info@HIBLOW-USA.com Email Contact Us! Contact
